DELTA DOP-107BV

Name: DELTA DOP-107BV
Brand: SANJAR AUTOMATION
Price: 1450.0 INR
Availability: InStock

Price 1450.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

DELTA DOP-107BV Specification

Overheating Protection
NO

Insulation Material
Plastic

Humidity %
10% to 90% RH (non-condensing)

Mounting Type
Panel Mounting

Operating Temperature
0°C to 50°C Celsius (oC)

Shape
Rectangular

Connector Type
Screw terminals, USB

Surface Finish
Matte

Feature
Touchscreen, Multi-Protocol Supported

IP Rating
IP65 (front panel)

Product Type
Human Machine Interface (HMI)

Application
Industrial Automation, Machine Operation Interface

Protection Level
Panel: IP65 (front side)

Frequency (MHz)
50/60 Hz Hertz (HZ)

Rated Voltage
24V DC Volt (V)

Output Type
TFT LCD Display

Color
Black

Dimension (L*W*H)
204 x 142 x 36 mm Millimeter (mm)

Weight
Approx. 0.81 kg Kilograms (kg)

Input Voltage
24V DC (10.2V to 28.8V) Volt (V)

Size
7-inch display

Material
Plastic (Front Panel); Aluminum (Back Case)

Connection Type
RS232/RS422/RS485, Ethernet, USB Host, USB Client

Backlight Life
50,000 hours (typical)

CE Certification
Yes

USB Host/Client
USB 2.0 Host x1, USB Client x1

Serial Ports
COM1: RS-232, COM2: RS-485/RS422, COM3: RS-232/RS485

Display Colors
16.7M Colors

Storage Expansion
MicroSD Slot (Max. 32GB)

Cooling Method
Natural air cooling

Touch Panel Type
Analog Resistive

Memory
128MB Flash, 128MB RAM

Resolution
800 x 480 pixels

Ethernet Port
10/100 Base-T

Display Type
TFT LCD with LED Backlight

DELTA DOP-107BV Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T)

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CAUSTOMER

Main Domestic Market
All India

Certifications
USED DELTA DOP-107BV

About DELTA DOP-107BV

Unlock exceptional operational efficiency for a limited time with the DELTA DOP-107BV, an enlightened choice for industrial automation. This grand 7-inch TFT LCD touchscreen delivers top-notch visual clarity with 16.7M colors and a vibrant 800 x 480 resolution. Engineered for longevity with a 50,000-hour backlight life and a matte IP65-protected front panel, its ideal for demanding applications. Find versatile connectivity with Ethernet, multiple serial ports, USB host/client, and MicroSD expansion. Elevate your interface design with this robust, CE-certified, and energy-efficient solution for machine operation.

Exceptional Application Surface and Versatile Advantages

The DELTA DOP-107BV excels as an operator interface, bringing a refined surface finish suitable for industrial control panels and machinery operation. Ideal for automotive, packaging, and process automation, its robust connectivity and multi-protocol support provide wide-ranging utility. Primary advantages include high durability, superior image quality, competitive pricing, and ease of integrationsetting it apart in the global market. Suppliers benefit from its reliability, user-friendly interface, and a flexible mounting system for diverse environments.

Prompt Delivery and Recognized Certifications

Orders for the DELTA DOP-107BV are typically delivered within a short span, ensuring minimal disruption during order completion. Exported mainly to markets in Asia, Europe, and the Middle East, this HMIs value outlay is justified by top-grade certifications like CE and an IP65-rated panel. As a certified supplier, trader, and service provider, timely dispatch and adherence to international standards are cornerstones of the transaction process.

FAQs of DELTA DOP-107BV:

Q: How can the DELTA DOP-107BV enhance my machine operation interface?

A: The DELTA DOP-107BV provides a responsive 7-inch touchscreen with high resolution and color depth, facilitating clear data visualization and intuitive control, which improves user experience and operational efficiency in machine interfaces.

Q: What communication options does the DELTA DOP-107BV support?

A: This HMI supports multiple communication protocols and features Ethernet, RS232, RS422, RS485 serial ports, as well as USB host/client connections and a MicroSD slot, allowing seamless integration with various industrial devices.

Q: Where can the DELTA DOP-107BV be mounted for optimal use?

A: It is designed for panel mounting, making it suitable for installation on industrial control panels or machine surfaces, offering flexibility for diverse operational environments.

Q: When should maintenance be performed on the display?

A: Maintenance intervals will depend on operating conditions, but routine cleaning of the main panel and checking connections is recommended to maintain performance. The backlights typical life of 50,000 hours minimizes frequent replacement needs.

Q: What is the benefit of the IP65 panel rating?

A: An IP65 front panel rating ensures robust resistance against dust and water, making the DELTA DOP-107BV highly reliable in challenging industrial settings.
