MESSUNG 32 I/P SURCE/SINK 6 MA @24V DC

Name: MESSUNG 32 I/P SURCE/SINK 6 MA @24V DC
Brand: SANJAR AUTOMATION
Price: 1600.0 INR
Availability: InStock

Price 1600.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MESSUNG 32 I/P SURCE/SINK 6 MA @24V DC Specification

Surface Finish
Matte

Insulation Material
ABS Plastic

IP Rating
IP20

Shape
Rectangular

Power Factor
Not applicable (DC device)

Connector Type
Screw type terminal

Humidity %
10% - 90% Non-condensing

Mounting Type
DIN Rail Mountable

Efficiency
High

Operating Temperature
0°C to 60°C Celsius (oC)

Feature
LED status indicators, removable terminals

Product Type
Digital Input Module

Application
Industrial automation, PLCs

Protection Level
Overvoltage and reverse polarity protection

Rated Voltage
24V DC Volt (V)

Output Type
Source/Sink

Color
Blue / Grey

Dimension (L*W*H)
Approx. 110 mm x 61 mm x 23 mm Millimeter (mm)

Weight
Approx. 120 g Grams (g)

Input Voltage
24V DC Volt (V)

Size
Compact

Phase
Single Phase

Connection Type
Screw Terminal

No Of Poles
32

Material
Industrial grade plastic, PCB components

PLC Compatibility
Suitable for Messung & other industrial standard PLCs

Current Per Channel
6 mA @ 24V DC

Module Identification
MESSUNG 32 I/P SOURCE/SINK

Number of Inputs
32 independent isolated channels

Minimum Input Voltage
16V DC (Guaranteed ON Voltage)

Standards Compliance
CE Marked, RoHS Compliant

Operation Indicator
Channel-wise LED indication

Isolation Voltage
500V AC (channel to channel)

Response Time
<10 ms

Noise Immunity
High, with opto-isolated inputs

Field Wiring
Removable connectors for easy wiring

Input Type
Digital sourcing/sinking

Maximum Input Voltage
30V DC (Absolute Max)

MESSUNG 32 I/P SURCE/SINK 6 MA @24V DC Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Day

Delivery Time
1 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
AS PER CAUSTOMER

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
USED MESSUNG 32 I P SURCE SINK 6 MA 24V DC

About MESSUNG 32 I/P SURCE/SINK 6 MA @24V DC

Unlock instantaneous access to superior industrial automation with the celebrated MESSUNG 32 I/P SOURCE/SINK 6 MA @24V DC module. This ravishing device boasts 32 pivotal independent isolated channels, each delivering unwavering performance at 6 mA. Hot deals await those seeking high noise immunity, rapid response times (<10 ms), and channel-wise LED indications. Its robust industrial-grade plastic construction and DIN rail mountable, compact rectangular shape exemplify reliability. Benefit from instant checkout for assured overvoltage/reverse polarity protection, removable connectors for easy wiring, and seamless PLC compatibility. Trust Messungs legacy for optimal operation in demanding environments.

Superior Performance & Versatility

The MESSUNG 32 I/P SOURCE/SINK 6 MA @24V DC module excels in industrial automation and is pivotal for high-speed PLC control systems. Its main competitive advantage is the independent channel isolation, offering unmatched protection and reliability. Supported applications include manufacturing, process control, and machinery automation. The modules compact size, advanced noise immunity, and overvoltage protection make it ideal for critical installations across celebrated industries.

Efficient Delivery & Secure Packaging

Domestically market-valued for its reliability, Messung ensures prompt offer fulfillment with swift delivery timeframes. The MESSUNG 32 I/P module is packaged securely in sturdy, tamper-proof containers to prevent damage during transit. Supply ability is robust, catering both to single-unit requirements and bulk orders for service providers, suppliers, and traders across India. Each module retains its celebrated market value thanks to consistent domestic mar distribution.

FAQs of MESSUNG 32 I/P SURCE/SINK 6 MA @24V DC:

Q: How does the MESSUNG 32 I/P SOURCE/SINK module enhance industrial automation?

A: This module significantly improves system protection and response speed, offering 32 isolated digital inputs with LED indicators and advanced noise immunity tailored for high-performing PLC setups.

Q: What kind of input channels are available in this device?

A: Each of the 32 channels supports digital sourcing or sinking, independently isolated to ensure operational safety and reliability.

Q: When is it beneficial to use this module within automation systems?

A: Its especially useful in environments demanding pivotal noise immunity, rapid input response, and reliable PLC compatibilitysuch as manufacturing, machinery control, and process automation.

Q: Where can the MESSUNG 32 I/P SOURCE/SINK be installed?

A: Its compact, DIN rail mountable design allows seamless integration in control panels, machinery enclosures, and industrial automation sites.

Q: What is the process for wiring and connecting this module?

A: Field wiring is simplified with removable connectors and screw-type terminals, allowing easy installation, maintenance, and modular setups.

Q: How does the modules protection features benefit users?

A: Users benefit from embedded overvoltage and reverse polarity protection, ensuring safety and longevity for both the module and connected PLC systems.
